New New New!!!!!! Garmin EchoMap52 DV จีพีเอส+ซาวเดอร์ 3D เมนูไทย 21500 บาท

เครื่องศูนย์ Garmin Thailand พร้อมแผนที่ละเอียด

New New New!!!!!! Garmin EchoMap52 DV จีพีเอส+ซาวเดอร์ 3D เมนูไทย 21500 บาท
เครื่องศูนย์ Garmin Thailand พร้อมแผนที่ละเอียด

บางเสร่ มารีน (ร้านอ้อมฟิชชิ่ง)
120/66 ม.8 ต.บางเสร่ อ.สัตหีบ จ.ชลบุรี

โทร.084 7905287 กฤษณ์

กฤษณ์ ธรรมนิติเวทย์
ธนาคาร กรุงไทย 2530 110 700

ตกปลาได้ทั้งวันทั้งคืนกับหน้าจอสี 5 นิ้วและปุ่มกด

แผนที่ฐานทั่วโลก

ระบบโซนาร์ในตัว 500W(RMS)HD-ID(4,000 วัตต์สูงสุด) / ความลึกสูงสุด: 335 เมตร(น้ำเค็ม) 700 เมตร(น้ำจืด)

ระบบโซนาร์ในตัวแบบ DownVü ที่สแกนภาพใต้น้ำอย่างชัดเจน

รวมหัวส่งสัญญาณ 50/200 เฮิร์ทซ์ HD- ID/DownVü มาในกล่อง

รวมตัวติดตั้งท้ายเรือ

รองรับพอร์ต NMEA 0183 ใช้สำหรับการแชร์ข้อมูลของจุดเวย์พอยท์และเส้นทาง

5 Hzในการปรับตำแหน่ง GPS และทิศทางมุ่งหน้า 5 ครั้งต่อวินาทีเพื่อให้แม่นยำต่อการทำเครื่องหมายและการวนกลับมาตำแหน่ง ต่างๆอย่างถูกต้อง

ติดตั้งและถอดเครื่องออกจากกรอบขาตั้งได้อย่างรวดเร็วสะดวกสำหรับการถอดเก็บรักษา

มีช่องใส่ microSD ™ การ์ดทำให้ง่ายต่อการเพิ่มแผนที่

รองรับแผนที่ BlueChart®g2

รองรับแผนที่ BlueChart® g2 Vision กับการนำร่องอัตโนมัติของ Garmin


5-inch Combo with Great Features for the Money

- High-contrast color display with keypad control with preloaded worldwide basemap
- Built-in DownVü scanning sonar with the clearest images on the water¹
- Built-in 500 W (RMS) HD-ID™ sonar (4,000 W peak-to-peak)
- 5 Hz Internal GPS updates position and heading 5 times per second
- Tilt/swivel quick-disconnect mount


echoMAP 52dv includes a 5-inch high-contrast colour display with automatic backlight adjustment. Fast, responsive 5 Hz GPS/GLONASS refreshes your position and heading 5 times each second to make your movement on the screen more fluid. echoMAP 52dv comes with a GT21-TM transducer for 50/200 kHz HD-ID sonar and Garmin DownVü™, the clearest scanning sonar on the wate(echoMAP 52dv is also available without transducer). It also supports Minn Kota® and MotorGuide® trolling motors with integrated transducers. The combo's cords plug directly into the mount, allowing you to quickly install and remove your device from power and the mount. Transom and trolling motor mount included.

Clearest Scanning Sonar on the Water

Garmin DownVü™ scanning sonar gives you a nearly photographic image down to 230 meters below your boat. You clearly see structure, submerged objects and fish! Traditional Garmin HD-ID sonar and DownVü scanning sonar are combined into one transducer. Also provides HD-ID support for Minn Kota and MotorGuide trolling motors with integrated transducers. The echoMAP 52dv also includes sonar-recording capability that coordinates the timing of the sonar return with your boat's position and saves digital information for playback on a computer using free HomePort™ planning software. Use the User Data Sharing Cable to share waypoints and routes between multiple devices.

Add Extras with BlueChart g2 Vision

With the optional BlueChart g2 Vision SD card, you can add a whole new dimension of exceptional features to your chartplotter.

MarinerEye view and FishEye view provide a 3-D perspective, both above and below the waterline.
High-resolution satellite images and aerial photographs help orient you in unfamiliar areas.
Auto Guidance technology searches through all relevant charts to create a route you can actually follow — one that avoids obstacles, shallow water, buoys and other obstructions. Just enter your destination and Auto Guidance will take you there on a safe path.

Heading and Position Refreshed 5 Times per Second

Fast, responsive 5 Hz GPS/GLONASS refreshes your position and heading 5 times each second to make your movement on the screen more fluid. It makes dropping up to 5,000 accurate waypoints and finding your way back to your secret fishing hot spots quick and easy.

Take Your echoMAP with You

When you’re off the water, it’s easy to keep your echoMAP safe and secure. You don’t have to mess with plugging and unplugging wires from the unit because the cords plug directly into the mount. This allows you to quickly install and remove your echoMAP from power and the mount.

Enhanced Auto Guidance

Just enter the location where you want to go and patented Garmin Auto Guidance technology instantly searches through relevant charts to create a safe virtual pathway on the display that helps you avoid low bridges, shallow water and other charted obstructions en route.

Better still, with enhanced Version 2.0, you now have access to even more features and capabilities. You’re able to adjust the calculated Auto Guidance pathway by inserting “via” points at interim stops or landmarks along your desired route. You can easily review hazard points along your calculated path. And you can even engage your compatible Garmin autopilot to follow the Auto Guidance route, automatically. Other 2.0 enhancements give you the ability to calculate arrival times at any point on your route (great for timing arrivals to correspond with bridge openings and other time-critical events). Better still, you can now save your plotted Auto Guidance paths for future navigation by backing them up on an SD™ card with your BlueChart® g2 Vision® or Lake Vü™ HD Ultra cartography².

GPX Waypoints Transfer

If you have waypoints, tracks or frequently used routes stored on another manufacturer’s GPS product – or on a Garmin handheld device – now it’s easier than ever to transfer those items to your new Garmin chartplotter, via industry-standard GPX software formatting. GPX is an open standard format for GPS data exchange across platforms and applications. With this easy-to-use interface technology, Garmin has taken “no waypoint left behind” to a whole new level of trade-up convenience.


Physical & Performance

Physical dimensions 15.0 x 15.5 x 6.1 cm
Display size, WxH 7.6 x 10.2 cm; 12.7 cm diagonal
Display resolution, WxH 480 x 480 pixels
Display type WQVGA display
Weight 0.7 kg
Water rating IPX7
Antenna Internal only
NMEA 0183 compatible Yes
Power consumption 7.1W
Mounting options Bail or flush
Garmin Marine Network™ ports None

Maps & Memory

Preloaded maps None
Accepts data cards 1 microSD™ card
Waypoints 3,000
Routes 100
Track log 20,000 points; 50 saved tracks

Chartplotter Features

Garmin Sonar compatible Yes
Supports AIS (tracks target ships position) Yes
Supports DSC (displays position data from DSC-capable VHF radio) Yes
Tide tables Yes
BlueChart® Mobile (planning) compatible No

Sonar Features & Specifications

Dual-frequency (50/200 kHz) sonar capable Yes
Transmit power 500 W (RMS) / 4,000 W (peak to peak)
DownVü™ Yes (built-in)
SideVü™ No
Maximum depth 700m @ 77 kHz, freshwater
335m @ 77 kHz, saltwater
(depth capacity is dependent on water bottom type and other water conditions)
Bottom lock (shows return from the bottom up) Yes
Water temperature log and graph Yes
Sonar recording Yes
Sonar history rewind Yes

Connections

NMEA 0183 input ports 1
NMEA 0183 output ports 1
Video input ports None
Video output ports None
Wireless connectivity No
